頻率：27.12MHz
尺寸：3.2*2.5mm
LFXTAL059815RL3K,CFPX-180,IQD高頻率電子,高精度晶振,小型晶振,四腳貼片晶振,環保晶振,電子產品晶振,電子門鎖晶振,6G信號臺晶振,高頻率晶振,編碼:LFXTAL059815RL3K,型號:CFPX-180,頻率:24.12MHz,吸塵器晶振,電子手表晶振,空調晶振,飛機晶振,無線鼠標晶振,數碼相機晶振,
LFXTAL059815RL3K,CFPX-180,IQD高頻率電子,高精度晶振
| 原廠編碼 | LFXTAL059815RL3K |
| 頻率 | 27.12MHz |
| 廠家 | IQD晶振 |
| 型號 | CFPX-180 |
| 頻率偏差 | ±50ppm |
| 負載電容 | 10pF |
| 工作溫度 | -40°C至85°C |
| 尺寸 | 3.2*2.5mm |
| Mfr Part # | Mfr | Series | Frequency | Frequency Tolerance | Load Capacitance |
| LFXTAL055299REEL | IQD 進口晶振 | CFPX-180 | 25 MHz | ±20ppm | 18pF |
| LFXTAL055474REEL | IQD 進口晶振 | CFPX-180 | 25 MHz | ±50ppm | 16pF |
| LFXTAL059648REEL | IQD 進口晶振 | CFPX-180 | 40 MHz | ±20ppm | 18pF |
| LFXTAL072604REEL | IQD 進口晶振 | CFPX-180 | 25 MHz | ±10ppm | 8pF |
| LFXTAL069882REEL | IQD 進口晶振 | CFPX-180 | 12 MHz | ±30ppm | 10pF |
| LFXTAL070065REEL | IQD 進口晶振 | CFPX-180 | 24 MHz | ±10ppm | 9pF |
| LFXTAL055293REEL | IQD 進口晶振 | CFPX-180 | 14.7456 MHz | ±50ppm | 18pF |
| LFXTAL009650REEL | IQD 進口晶振 | CFPX-180 | 16 MHz | ±10ppm | 16pF |
| LFXTAL055295REEL | IQD 進口晶振 | CFPX-180 | 12 MHz | ±20ppm | 18pF |
| LFXTAL082076REEL | IQD 進口晶振 | CFPX-180 | 32 MHz | ±10ppm | 8pF |
| LFXTAL057997REEL | IQD 進口晶振 | CFPX-180 | 16 MHz | ±10ppm | 10pF |
| LFXTAL056346REEL | IQD 進口晶振 | CFPX-180 | 12 MHz | ±30ppm | 18pF |
| LFXTAL083138RL3K | IQD 進口晶振 | CFPX-180 | 8 MHz | ±30ppm | 12pF |
| LFXTAL059611RL3K | IQD 進口晶振 | CFPX-180 | 13.56 MHz | ±20ppm | 18pF |
| LFXTAL054208RL3K | IQD 進口晶振 | CFPX-180 | 12 MHz | ±10ppm | 10pF |
| LFXTAL035265REEL | IQD 進口晶振 | CFPX-180 | 20 MHz | ±50ppm | 16pF |
| LFXTAL070868REEL | IQD 進口晶振 | CFPX-180 | 12 MHz | ±10ppm | 18pF |
| LFXTAL055951REEL | IQD 進口晶振 | CFPX-180 | 16 MHz | ±30ppm | 18pF |
| LFXTAL035266REEL | IQD 進口晶振 | CFPX-180 | 24 MHz | ±50ppm | 16pF |
| LFXTAL063321REEL | IQD 進口晶振 | CFPX-180 | 25 MHz | ±50ppm | 18pF |
| LFXTAL059643REEL | IQD 進口晶振 | CFPX-180 | 26 MHz | ±20ppm | 18pF |
| LFXTAL059815REEL | IQD 進口晶振 | CFPX-180 | 27.12 MHz | ±50ppm | 10pF |
| LFXTAL053866REEL | IQD 進口晶振 | CFPX-180 | 48 MHz | ±20ppm | 18pF |
| LFXTAL058124REEL | IQD 進口晶振 | CFPX-180 | 24 MHz | ±20ppm | 18pF |
| LFXTAL051068REEL | IQD 進口晶振 | CFPX-180 | 25 MHz | ±50ppm | 9pF |
| LFXTAL055962REEL | IQD 進口晶振 | CFPX-180 | 30 MHz | ±10ppm | 12pF |
| LFXTAL071177REEL | IQD 進口晶振 | CFPX-180 | 24 MHz | ±10ppm | 9pF |
| LFXTAL083408RL3K | IQD 進口晶振 | CFPX-180 | 25 MHz | ±20ppm | 12pF |
| LFXTAL083388RL3K | IQD 進口晶振 | CFPX-180 | 12 MHz | ±20ppm | 12pF |
| LFXTAL083387RL3K | IQD 進口晶振 | CFPX-180 | 10 MHz | ±20ppm | 12pF |
| LFXTAL035522REEL | IQD 進口晶振 | CFPX-180 | 32 MHz | ±10ppm | 9pF |
