Quarztechnik Quartz Crystal詳細說明書，這是一家有著50多年元器件經驗的晶振品牌公司Quarztechnik，一直以來，秉持著創新的設計理念，持續不斷為行業創造巨大的價值，同時，對于產品品質的極致追求，使得其走向非凡的道路，總能以滿足用戶的需求為主，針對新興領域打磨一系列高質量的產品，其中最為主流的石英晶振一直備受市場的歡迎，Quarztechnik利用自身的優勢，做到高品質低損耗低功耗的特點。

我必須承認:當我在近五個月前加入Quarztechnik的營銷團隊時，我對頻率元件一點概念都沒有。我不知道石英是什么，它看起來像什么，也不知道它與振蕩器有什么不同。當然，現在這種情況已經改變了，這要感謝我的技術同事們的耐心和詳細的解釋。

在過去的幾個月里，我對晶體和振蕩器了解得越多，我就越意識到頻率產品在我們的日常生活中無處不在！沒有頻率發生器的典型日常工作？難以想象。讓我給你舉幾個我個人日常生活中的例子。

石英保證了精確的時間測量

我的一天從鬧鐘響起開始。這已經是石英最經典的應用領域:發條裝置。20世紀70年代，從機械操作的鐘表到電動石英表的轉變石英產品首次進入大眾市場。

當連接到外部電源時，石英以穩定的頻率振蕩，這決定了鐘表機構的節奏。簡而言之，石英確保手表“知道”一秒持續多長時間。由于產生的頻率總是保持完全相同，石英晶體被認為是時間測量最高精度的保證。

智能控制電子學

起床后半個小時，我坐在車?yán)锶ド习唷＿^(guò)了一會兒，第一滴雨點落下來了。雨量傳感器開始工作，雨量感應雨刷有規律地工作。根據水量的多少，或快或慢，正如控制電子設備中使用的石英所指示的那樣。但不僅僅是雨量傳感器:轉向指示燈、舒適座椅調節和轉向柱電子設備也依賴石英晶體作為頻率發生器。

大雨使我沮喪，我需要音樂。因?yàn)闊o(wú)線電流行音樂太可怕了，我把手機通過藍牙連接到汽車的音響系統，開始播放自己的音樂。為了使手機和汽車之間的交流順利進行，它們必須以完全相同的無線電頻率相互通信。你可能已經懷疑石英是照顧這一點。

數據和信息的無線交換已經成為頻率元件最重要的應用領域之一。這適用于健身腕帶和智能手表等可穿戴設備，它們將數據傳輸?shù)脚宕髡叩闹悄苁謾C(jī)，也適用于作為物聯網應用的一部分相互通信的智能生產機器。在所有這些情況下，石英晶體Quartz crystal提供精確的無線電頻率，并確保發射機和接收機在同一波長上。

當我到達辦公室時，我做的第一件事是啟動我的電腦。Windows 10向我展示了一幅風景如畫的火山景觀，上面的時間是:8:20。時間測量再次由石英控制。順便說一句，微波爐的計時器也是如此，我，這個吝嗇鬼，正在加熱我從家里帶來的燉菜。

你看:盡管它們很低調，但在日常生活中，石英晶體和振蕩器幾乎是不可替代的。它們只有幾毫米大小，卻是從收音機鬧鐘到電腦等眾多電子應用中不可或缺的一部分。

有關石英晶體和振蕩器如何工作的更多信息，請參閱我們的“詢問工程師”系列。我們的技術支持主管解釋道音叉晶體如何工作和哪些方法用于生產高精度石英晶體。Quarztechnik Quartz Crystal詳細說明書.

When I joined Quarztechnik’s marketing team almost five months ago, I didn’t have the slightest idea about frequency components. I didn’t know what a quartz was, what it looked like or how it differed from an oscillator. Of course, this has now changed, thanks to the patient and detailed explanations of my technical colleagues.

The more I learned about crystals and oscillators over the last few months, the more I became aware that frequency products can actually be found everywhere in our everyday lives! A typical daily routine without frequency generators? Hard to imagine. Let me give you a few examples from my personal everyday life.

The Quartz Guarantees Precise Time Measurement

My day starts with the ringing of my alarm clock. And that’s already the most classic field of application for quartzes: The clockwork. The transition from mechanically operated clockworks to electrically operated quartz watches in the 1970s was thefirst time that quartz-products entered the mass market.

When connected to an external power source, the quartz oscillates at a stable frequency that determines the rhythm of the clockwork. Put simply, the quartz ensures that the watch “knows” how long a second lasts. Since the generated frequency always remains exactly the same, quartz crystals are considered as guarantee for the highest precision in time measurement.

Intelligent Control Electronics

Just half an hour after getting up I sit in the car on my way to work. A short time later the first raindrops fall. The rain sensor strikes and the rain-sensing wipers do their work in a regular rhythm. Depending on the amount of water, slower or faster, just as the quartz used in the control electronics dictates. But it’s not just the rain sensor: The turn indicator blinker, the comfort seat adjustment and the steering column electronics also depend on quartz crystals as frequency generators.

The heavy rain depresses me, I need music. Because radio-pop is horrible, I connect my mobile phone via Bluetooth to the car’s sound system and start my own playlist. For the exchange between mobile phone and car to function smoothly, they have to communicate with each other on exactly the same radio frequency. You probably already suspect that a quartz is taking care of that.

Wireless: The Quartz Ensures the Correct Frequency

The wireless exchange of data and information has become one of the most important application areas for frequency components. This applies to wearables such as fitness wristbands and smartwatches, which transmit their data to the wearer’s smartphone, as well as to intelligent production machines that communicate with each other as part of IoT applications. In all these cases, quartz crystals provide precise radio frequencies and ensure that the transmitter and receiver are literally on the same wavelength.

When I arrive at the office, the first thing I do is start my computer. Windows 10 shows me a picturesque volcanic landscape and above it the time: 8:20. Once again the time measurement is controlled by a quartz. By the way, the same holds true for the timer of the microwave, in which I, the scrimper, warm up my Ratatouille that I brought from home.

You see: Despite their low profile, there is hardly a way around quartz crystals and oscillators in everyday life. Only a few millimeters in size, they are an indispensable part of numerous electronic applications – from radio alarm clocks to computers.

For more information on how quartz crystals and oscillators work, please see our “Ask the Engineer” series. Here our Head of Technical Support, explainshow tuning fork crystals workandwhich methods are used in the production of high-precision quartz crystals.
